QuicRun 10BL60 & 120 Sensored

Easy Operation

This ESC is specially designed for new beginners and intermediate modelers;
it not only carries forward the outstanding quality of HOBBYWING products
but simplifies the operation.

Easy Operation

Compact Design &
SD/SL Dual Mode Supported

With the compact design, it’s applicable to various chassis.
With the Dual (Sensored/Sensorless) Drive Mode,
it’s compatible with different motors and brings
racers two different control feel.

Compact Design & SD/SL
Dual Mode Supported

High Reliability & Durability

Reliable hardware combined with advanced software technology allows
the QUICRUN 10BL60-SD to not only provide high power output but also
overload protection of the ESC circuit.

High Reliability
& Durability

Efficient Cooling System

Hobbywing patented heat-conductive copper bar cover on the power board
of the QUICRUN 10BL60-SD, which can efficiently and effectively transfer heat to the
integrated CNC machined billet aluminum heat sink housing, combined with
high-performance cooling fan can keep your ESC as cool as possible.

Efficient Cooling System

Single-button Programming & Factory Reset

The SET button on the ESC allows the user to easily program or factory reset the ESC with ease.

Single-button Programming
& Factory Reset

Wide Applicability

This ESC is designed for practice and daily training of1/10th, 1/12th scale touring cars, buggies, and F1.

Wide Applicability

Product Name
Product Number
Type Scale

Brushed/Brushless

Sensored/Sensorless

Waterproof
Specifications Cont./Peak Current

Input

BEC Output
Wires & Connectors Input Wires

Output Wires

Input Connectors

Output Connecotors
ESC Programing via SET Button on ESC

LED Program Box

LCD Program Box

WiFi Module

OTA Programmer

Program Port
Fan Size

Voltage Range

Powered by


Firmware Firmware Upgrade
Size & Weight Size

Weight
Applications Motors

Vehicles

KV Rating/T Count
Product Name QuicRun 10BL60 Sensored QuicRun 10BL120 Sensored
Product Number 30108000 30125000
Type Scale

Brushed/Brushless

Sensored/Sensorless

Waterproof		 1/10th

BL

SD

No		 1/10th

BL

SD

No
Specifications Cont./Peak Current

Input

BEC Output		 60A/380A

2-3S LiPo/6-9 Cell NiMH

Linear Mode:6V/2A		 120A/760A

2-3S Lipo/5-9 Cell NiMH

Linear Mode:6V@3A
Wires & Connectors Input Wires

Output Wires

Input Connectors

Output Connecotors		 Red-12AWG-200mm*1/Black-12AWG-200mm*1

Blue-12AWG-200mm*1/Yellow-12AWG-200mm*1/Orange-12AWG-200mm*1

No

No		 Red-12AWG-200mm*1/Black-12AWG-200mm*1

Blue-12AWG-200mm*1/Yellow-12AWG-200mm*1/Orange-12AWG-200mm*1

No

No
ESC Programing via SET Button on ESC

LED Program Box

LCD Program Box

WiFi Module

OTA Programmer

Program Port

 Supported

Supported

Not Supported

Not Supported

Not Supported

Program/Throttle Wire		 Supported

Supported

Not Supported

Not Supported

Not Supported

Program/Throttle Wire
Fan Size

Voltage Range

Powered by



 25.0x25.0x10.0mm

5-8.4V

Powered by BEC



 25x25x10mm

5-8.4V

(Powered by the Battery)

Note: When using a 3S Lipo battery, please replace the fan that can support 12V voltage!
Firmware Firmware Upgrade Not Supported Not Supported
Size & Weight Size

Weight		 33 x 28 x 31.5mm (w/ Fan)

59g		 43 x 36 x 33mm (w/ Fan)

105g105g (w/ Wires)
Applications Motors

Vehicles

KV Rating/T Count		 SL BL Motors/SD BL Motors

1/10th Touring Cars/Buggies/Drift Cars/F1

22S LiPo: 1/10th Touring Cars≥8.5T, 1/10th Buggies≥13.5T 3S LiPo: 1/10th Touring Cars≥13.5T, 1/10th Buggies≥17.5T (3650 Motors)		 SL BL Motors/SD BL Motors

1/10thTouring Cars/Buggies/Drift Cars/F1

2SLipo: 1/10thTouring Cars≥4.5T；1/10th Buggies≥5.5T

3SLipo: 1/10thTouring Cars≥10.5T；1/10th Buggies≥13.5T



Programmable Items

Installation & Connection

Sensored motor wiring
When using sensored brushless motor, please connect the “SENSOR” port of the ESC and the the “SENSOR” port of the motor with a sensor wire.
For sensored brushless motor, the #A, #B, #C wires of the ESC MUST be connected with the motor wire #A, #B, #C respectively. Do not change the wires sequence optionally! (#A is Blue, #B is Yellow, #C is Orange.)

Sensorless motor wiring
When using sensorless brushless motor, the #A, #B, #C wires of the ESC can be connected with the motor wires freely (without any order). If the motor runs in the opposite direction, please swap any two wire connections. Please disconnect the battery from the ESC after running the car!
