XeRun XR10 Justock G3 Handout

Built to fair race
The XR10 Justock G3-Handout ESC,
together with Justock-Handout motor are designed for fair and competitive racing.
The reliable characteristics of the HOBBYWING electronics ensures safe operation
and consistent power output over a long period of time.
Built to fair race
RPM speed limit function
Supports 6-speed RPM speed limit value selection and is able to match different motor
speed to meet the speed limit requirements of various levels of competition
and different vehicle on the market; the RPM speed limit value gear can be
identified through the ESC indicator; accurate speed limit Algorithms
ensures smooth throttle control.
RPM speed limit function
Zero timing
competition design
The internal timing of the ESC is fixed at 0 degrees and cannot be adjusted.
It is specifically built for zero timing races around the world.
Zero timing competition design
Support bi-directional
motor movement
The ESC supports both CCW (counterclockwise) and
CW (clockwise) motor rotational directions
for different usage on the market.
Directions
CCW
Directions
CW
Support bi-directional
motor movement
Built-in polarity protection
One danger that all electrical systems face is a reversed polarity from the power source.
This can be caused by a short circuit,
or usually, incidentally reversing the terminals.
The ESC is integrated using MOSFET.
If the battery terminals are connected in reverse,
the MOSFET will be reverse-biased and will not allow current
to flow through the system.
Built-in polarity protection
Built-in capacitor
module
The built-in capacitor module eliminates
the need for external capacitors
and unwanted space.
Built-in capacitor module
Built-in BEC supporting
high-voltage servo
The ESC has a built-in BEC which can support a maximum
output current of up to 8A and the output voltage at either 6V or 7.4V.
This will ensure constant power supplied
to today’s high-torque servos in the market.
Maximum output current of up to
Built-in BEC
User-friendly and
convenient for set-up
The ease of having a dedicated programming port eliminates
the trouble of plugging and unplugging the cable to the receive r.
In addition, the interface can power additional fans to
further dissipate heat.
The user-friendly interface allows for easy and
convenient setup by simply connecting the 3in1 LCD
programming box or OTA Bluetooth module to
the dedicated programming port.
dedicated programming port
Product Name
Product Number
Type Scale

Brushed/Brushless

Sensored/Sensorless

Waterproof
Specifications Cont./Peak Current

Input Voltage

BEC Output
Wires & Connectors Input Wires

Output Wires

Input Connectors

Output Connectors
ESC Programing via SET Button on ESC

LED Program Box

LCD Program Box

WiFi Module

OTA Programmer

Programming Port
Fan Size

Output Wires

Input Connectors
Data Recording Extreme value

Real-time Data

Historical data (Graph)
Firmware Firmware Upgrade
Size & Weight Size

Weight
Applications Applications

Vehicles

KV Rating/T Count
Product Name XERUN XR10 Justock G3 Handout
Product Number 30112004
Type Scale

Brushed/Brushless

Sensored/Sensorless

Waterproof		 1/10th

BL

SD

No
Specifications Cont./Peak Current

Input Voltage

BEC Output		 60A/380A

2S LiPo

6V/7.4V @4A,8A Peak
Wires & Connectors Input Wires

Output Wires

Input Connectors

Output Connectors		 Black-14AWG-200mm*2

Black-14AWG-200mm*3

No

No
ESC Programing via SET Button on ESC

LED Program Box

LCD Program Box

WiFi Module

OTA Programmer

Programming Port		 Supported

Supported

Supported

Supported

Supported

Separate
Fan Size

Output Wires

Input Connectors		 25x25x10mm

5-7.4V

Powered by BEC
Data Recording Extreme value

Real-time Data

Historical data (Graph)		 Not Supported

Not Supported

Not Supported
Firmware Firmware Upgrade Supported
Size & Weight Size

Weight		 40.9x33.9x32.1mm

75.4g(w/Wires)
Applications Applications

Vehicles

KV Rating/T Count		 SL BL Motors / SD BL Motors

1/10th,1/10th On-road and Off-road club competition and normal training

≥10.5T 3650 Motor
Support

Manuals & Documents

Manuals

Software Download

FAQ

Multifunction LCD Program Box

Multifunction LCD Program Box

Part Number: 30502001
Size: 91x51x17mm (LxWxH)
Applications: Platinum series of
brushless aircraft ESCs, XeRun
series & EzRun series of brushless
car ESCs, SeaKing Pro series of
brushless boat ESCs

+
OTA Programmer

OTA Programmer

Product Number: 30850400
Working Voltage: 5-12.6V
Supported Bluetooh Version: ≥ 4.0
Effective Range: 0-5m (Open Field)
Applications: work on the XzRun series,
EzRun series of car ESCs, and the Platinum
series of aircraft ESCs, and
Seaking Prp series of boat ESCs.

+
