VTOL Motors/ESCs/Propellers - VTOL Drone Propulsion Systems

Home > Drone Propulsion Systems > VTOL

XRotor Pro H300A 24S FOC V2

Input Voltage: 12-24S（36-130V）
Continuous current :140A
Weight（Without Cable）: 800g
Size: 175x76x47mm
Communication protocol: CAN/RS485(Serial Port Customizable)
lsolation mode: Throttle and Communication Isolation

XRotor Pro H300A 24S BLDC V3 / BLDC IPC V3

Input Voltage: 12-24S（36-110V）
Continuous current :150A
Weight（Without Cable）: 656g
Size: 146x70x46mm
Communication protocol: CAN/RS485(Serial Port Customizable)
lsolation mode: Throttle and Communication Isolation

V11122

Battery(LiPo): 24S LiPo
KV: 60KV
Weight（With wire): 1319g
Recommended Thrust/rotor: 20~23kg/Rotor
Protection level: IP45

V11130

Battery(LiPo): 24S LiPo
KV: 55KV
Weight（With wire): 1666g
Recommended Thrust/rotor: 23~26kg/Rotor
Protection level: IP45

Hobbywing P65V large drone motor

P65V

propulsion System for Industrial Drones

Thrust/rotor: 65kg
Weight (With Cable & Props): 6165±60g / 6252±60g
Recommended LiPo Battery: 96~107S (LiPo)
Propeller: 60x20"/54x23"
Propeller Positioning: IPC (Intelligent Propeller Control)

XRotor Pro H200A 24S BLDC/ BLDC IPC

Input Voltage: 36~108V
Continuous current :100A（Good heat dissipation）
Weight（Without Cable）: 420g
Size: 138x68x32.5mm
Communication protocol: CAN / RS485(Custom Serial port)
lsolation mode: Throttle/ communication supported

XRotor Pro H200A 14S BLDC Drone ESC

XRotor Pro H200A 14S BLDC

Input Voltage: 6-14S（18-63V）
Continuous current :100A（Good heat dissipation）
Weight（Without Cable）: 270g
Size: 116x56x31.5mm
Communication protocol: CAN(Custom Serial port)
lsolation mode: Throttle/ communication supported

XRotor Pro H200A 14S FOC Drone ESC

XRotor Pro H200A 14S FOC

Input Voltage: 6-14S（18-63V）
Continuous current :100A（Good heat dissipation）
Weight（Without Cable）: 270g
Size: 116x56x31.5mm
Communication protocol: CAN(Custom Serial port)
lsolation mode: Throttle/ communication supported

XRotor H150A 24S FOC V1

Input Voltage: 18-24S（54~104.4V）
Continuous current: 50A (Good heat dissipation)
Weight: 464g (Without wires)
Size: 164x66x38mm
Communication protocol: CAN(Custom Serial port)
Throttle signal isolated: Isolated

XRotor Pro H130A 14S FOC Drone ESC

XRotor Pro H130A 14S FOC

Input Voltage:6-14S（18-63V）
Continuous current: 60A（Good heat dissipation）
Weight（Without Cable）:148g
Size: 96.5x46x23.5mm
Communication protocol: CAN+485(Custom Serial port)
Throttle signal isolated: Throttle And Communication Isolation

XRotor Pro H130A 14S BLDC Drone ESC

XRotor Pro H130A 14S BLDC

Input Voltage:6-14S（18-63V）
Continuous current: 60A（Good heat dissipation）
Weight（Without Cable）:148g
Size: 96.5x46x23.5mm
Communication protocol: CAN+485(Custom Serial port)
Throttle signal isolated: Throttle And Communication Isolation

XRotor H100A 14S FOC V1

Input Voltage: 12~14S(44~63V)
Continuous current: 40A (Good heat dissipation)
Weight: 144.1g(Without wires)
Size: 83x59x27.4mm
Communication protocol: CAN
Throttle signal isolated: Isolated (Custom non-isolated)

<
