14S BLDC/FOC ESC for VTOL Drone | HOBBYWING®

Home > Drone Propulsion Systems > VTOL > ESC > 14S

Hobbywing ESC XRotor Pro H200A 14S BLDC

XRotor Pro H200A 14S BLDC

Input Voltage: 6-14S（18-63V）
Continuous current :100A（Good heat dissipation）
Weight（Without Cable）: 270g
Size: 116x56x31.5mm
Communication protocol: CAN(Custom Serial port)
lsolation mode: Throttle/ communication supported

Hobbywing ESC XRotor Pro H200A 14S FOC

XRotor Pro H200A 14S FOC

Input Voltage: 6-14S（18-63V）
Continuous current :100A（Good heat dissipation）
Weight（Without Cable）: 270g
Size: 116x56x31.5mm
Communication protocol: CAN(Custom Serial port)
lsolation mode: Throttle/ communication supported

Hobbywing ESC XRotor Pro H130A 14S FOC

XRotor Pro H130A 14S FOC

Input Voltage:6-14S（18-63V）
Continuous current: 60A（Good heat dissipation）
Weight（Without Cable）:148g
Size: 96.5x46x23.5mm
Communication protocol: CAN+485(Custom Serial port)
Throttle signal isolated: Throttle And Communication Isolation

Hobbywing ESC XRotor Pro H130A 14S BLDC

XRotor Pro H130A 14S BLDC

Input Voltage:6-14S（18-63V）
Continuous current: 60A（Good heat dissipation）
Weight（Without Cable）:148g
Size: 96.5x46x23.5mm
Communication protocol: CAN+485(Custom Serial port)
Throttle signal isolated: Throttle And Communication Isolation

Hobbywing ESC XRotor H100A 14S FOC V1

XRotor H100A 14S FOC V1

Input Voltage: 12~14S(44~63V)
Continuous current: 40A (Good heat dissipation)
Weight: 144.1g(Without wires)
Size: 83x59x27.4mm
Communication protocol: CAN
Throttle signal isolated: Isolated (Custom non-isolated)

Hobbywing ESC XRotor H80A 14S FOC

XRotor H80A 14S FOC

Input Voltage: 6-14S（18-63V）
Continuous current:40A（Good heat dissipation）
Weight（Without Cable）: 87g
Size: 84x35x20mm
Communication protocol:CAN(Custom Serial port)
Throttle signal isolated: Customizable Throttle Isolation

Hobbywing ESC XRotor H80A 14S BLDC

XRotor H80A 14S BLDC

Input Voltage: 6-14S（18-63V）
Continuous current:40A（Good heat dissipation）
Weight（Without Cable）: 87g
Size: 84x35x20mm
Communication protocol:CAN(Custom Serial port)
Throttle signal isolated: Customizable Throttle Isolation

Hobbywing ESC XRotor Pro H60A 14S BLDC

XRotor Pro H60A 14S BLDC

Input Voltage: 6-14S(18-63V)
Continuous current: 25A(Good heat dissipation)
Weight( without wire): 67g
Size: 78.5x32.5x18.4mm
Communication protocol: CAN(Custom Serial port)
lsolation mode: Customizable Throttle Isolation

Hobbywing ESC XRotor Pro H60A 14S FOC

XRotor Pro H60A 14S FOC

Input Voltage: 6-14S(18-63V)
Continuous current: 25A(Good heat dissipation)
Weight( without wire): 67g
Size:78.5x32.5x18.4mm
Communication protocol: CAN(Custom Serial port)
lsolation mode: Customizable Throttle Isolation

Hobbywing ESC XRotor H60A(2in1) 14S FOC V1

XRotor H60A(2in1) 14S FOC V1

Input Voltage: 6-14S(18-63V)
Continuous current: 15A×2 (Good heat dissipation)
Weight: 117.4g(Without wires)
Size: 77.5x47x26.8mm
Communication protocol: CAN(Custom Serial port)
Throttle signal isolated: Isolated

Hobbywing ESC XRotor H60A(2in1) 14S BLDC V1

XRotor H60A(2in1) 14S BLDC V1

Input Voltage: 6-14S(18-63V)
Continuous current: 15A×2 (Good heat dissipation)
Weight: 117.4g(Without wires)
Size: 77.5x47x26.8mm
Communication protocol: CAN(Custom Serial port)
Throttle signal isolated: Isolated
