Industry

H11M
H11M

Power System for Industrial Drones

New
Recommended Takeoff Weight：25~28kg/Rotor
Total Weight: 4357g
Recommended LiPo Battery: 14S
Diameter X Thread Pitch: 48*17.5"
Powertrain Arm Tube Outer Diameter: φ50mm
H6M&H8M
H6M&H8M

Power System for Industrial Drones

New
Recommended Takeoff Weight：H6M: 2~2.5kg / H8M: 2.5~3.5kg
Total Weight: H6M: 418g / H8M: 498g
Recommended LiPo Battery: 12S
Diameter X Thread Pitch: H6M: 22*7.8" / H8M: 30*9.8"
Powertrain Arm Tube Outer Diameter: φ30mm
XRotor H8V 8120 160KV
XRotor H8V 8120 160KV

XRotor H8V 8120 160KV

New
Stator Size: 81*20mm
KV Rating: 160KV
Weight: 530g
XRotor H150A 24S FOC V1
XRotor H150A 24S FOC V1

New
Input Voltage: 18-24s（54~104.4V）
Peak Current (3s): 50A (Good heat dissipation)
Weight: 464g (Without wires)
Size: 164*66*38mm
Communication protocol: CAN(Custom Serial port)
Throttle signal isolated: Isolated
XRotor H60A 24S FOC V1
XRotor H60A 24S FOC V1

Input Voltage: 18-24S（54~104.4V）
Peak Current (3s): 60A
Weight: 181.5g(Without wires)
Size: 113*56*25.9mm
Communication protocol: CAN(Custom Serial port)
Throttle signal isolated: Isolated (Custom non-isolated)
XRotor H100A 14S Foc V1
XRotor H100A 14S Foc V1

Input Voltage: 12~14S(44~63V)
Peak Current (3s): 40A (Good heat dissipation)
Weight: 144.1g(Without wires)
Size: 83*59*27.4mm
Communication protocol: CAN
Throttle signal isolated: Isolated (Custom non-isolated)
XRotor H120A 14S FOC V1
XRotor H120A 14S FOC V1

Input Voltage: 12-14S(44-63V)
Peak Current (3s): 60A (Good heat dissipation)
Weight: 185.6g(Without wires)
Size: 113*56*25.9mm
Communication protocol: CAN(Custom Serial port)
Throttle signal isolated: Isolated (Custom non-isolated)
XRotor H60A 14S FOC & BLDC V1
XRotor H60A 14S FOC & BLDC V1

Input Voltage: 12-14S(44-63V)
Peak Current (3s): 25A(Good heat dissipation)
Weight: 67g(Without wires)
Size: 75*35.5*20.3mm
Communication protocol: Serial port
Throttle signal isolated: Isolated (Custom non-isolated)
XRotor H120A 18S FOC V1
XRotor H120A 18S FOC V1

Input Voltage: 12-18s（44-78.3V）
Peak Current (3s): 40A (Good heat dissipation)
Weight: 234g (Without wires)
Size: 116*49.4*34.8mm
Communication protocol: CAN
Throttle signal isolated: Isolated
XRotor H300A 24S FOC & BLDC V1
XRotor H300A 24S FOC & BLDC V1

Input Voltage: 18-24S（54~104.4V）
Peak Current (3s): 120A(Good heat dissipation)
Weight: 1054.3g(Without wires)
Size: 213*71*61mm
Communication protocol: CAN(Custom Serial port)
Throttle signal isolated: Isolated
XRotor H60A(2in1) 14S FOC & BLDC V1
XRotor H60A(2in1) 14S FOC & BLDC V1

Input Voltage: 6-14S(18-63V)
Peak Current (3s): 15A(Good heat dissipation)
Weight: 117.4g(Without wires)
Size: 77.5*47*26.8mm
Communication protocol: CAN(Custom Serial port)
Throttle signal isolated: Isolated
