Low voltage, high power
X11PLUS 11118-85KV
carbon-plastic propellers 4314 ,recommend take-offweight 15-18kg/rotor.
PWM analog signal + CAN digital signal , precise throttle control, more stable flight.
Even in the state of single GPS without RTK, "fixed" flight.
*The data was tested at sea level
Fault storage
Built-in fault storage function. Use the DATALINK data
box to download and view, and convert the fault into
data, which helps the UAV to quickly locate
problems and analyze faults.
Multiple Intelligent Protection V2.0
In response to overcurrent, stalled and other working conditions,
the fault processing time is shortened to within 270ms, and
various emergencies can be handled instantaneously to ensure
flight safety.
IPX6 Protection
The ESC is fully sealed and protected, further improving
anti-corrosion and anti-rust level of the motor
Higher tension
higher efficiency
It surpasses the X11-18S in all ways by answering
to low voltage and high power requirements.

Compared to the X11 18S,
the system efficiency is improved
The same conditions, fly longer.

The maximum thrust has
increased to 37kg, with 4314
carbon plastic propellers,

Good heat dissipation
The heat dissipation structure of the
motor has been upgraded to bring more
powerful active heat dissipation.
Under the same working conditions, the
heat dissipation effect is better
than that of X11-18S.
Multiple protection function

The X11-Plus power system is equipped with several protection
functions such as:Power-on self-test, Power-on voltage abnormal
protection, Current protectionand Stall protection. It is able to
output an operating status data to the flight controller in real time

Note: Using the Hobbywing DataLink data acquisitionmemory can
simultaneously collect the real-time operation dataof the 8-channel
power system, and pass it to theflight controller through the bus
interface toform a closed-loop control system.

Communication & Upgrade
The default CAN communication (serial port is optional),
real-time transmission of powersystem working condition
data, real-time detection of system working status,
making flight more at ease. Use the Hobbywing DATALINK
Data box to upgradethe ESC firmware online, and also support
remote upgrade through theflight controller, synchronization
of Hobbywing latest technology.
* Hobbywing CAN protocol has successfully communicated with some flight controller.
For the closed source flight controller, contact the manufacturer for instructions.
For the open source Ardupilot flight controller,refer
https://ardupilot.org/copter/docs/common-hobbywing-dronecan-esc.html
XRotor X11 plus CAD
Product Name
XRotor X11 PLUS
Specifications
Max Thrust 37kg/rotor(54V, Sea Level)
Recommended Takeoff Weight 15-18kg/rotor(54V, Sea Level)
Recommended Battery 12-14S(LiPo)
Operating Temperature 0~50℃
Total Weight 2490g
Ingress Protection IPX6
Motor
KV Rating 85rpm/V
Stator Size 111*18mm
Powertrain Arm Tube Outer Diameter 50mm
Bearing Bearings imported from Japan
ESC
Recommended LiPo Battery 12-14S(LiPo)
PWM Input Signal Level 3.3V/5V
Throttle Signal Frequency 50-500Hz
Operating Pulse Width 1050-1950-us(Fixed or cannot be Programmed)
Max. Input Voltage 61V
Max. Input Current (Short duration) 150A(With/ Good Heat Dissipation)
BEC No
Propeller
Diameter×Pitch 43*14
XRotor X11 Plus Techenical Parameters

Voltage(V)

Propeller(Inch)

Throttle(%)

Thrust(g)

Current(A)

Power(W)

Speed(RPM)

Efficiency(g/W)

54V (14S LIPO)

HW 43*14Inch Foldable Propeller

40%

10065

18.9

1024.3

1758

9.8

42%

10875

21.2

1148.8

1827

9.5

44%

12110

24.9

1347.1

1927

9.0

46%

13170

28.2

1525.6

2009

8.6

48%

14000

30.9

1670.7

2071

8.4

50%

15040

34.3

1859.2

2147

8.1

52%

16200

38.4

2078.4

2228

7.8

54%

17305

42.4

2295.7

2303

7.5

56%

17870

44.5

2410.1

2341

7.4

58%

18755

47.9

2593.8

2398

7.2

60%

19810

52.1

2819.9

2466

7.0

62%

21230

57.9

3136.3

2554

6.8

64%

21825

60.5

3272.9

2590

6.7

66%

23030

65.7

3557.4

2662

6.5

68%

24230

71.2

3850.7

2731

6.3

70%

25775

78.4

4243.3

2818

6.1

72%

26215

80.5

4358.1

2842

6.0

74%

27390

86.4

4671.8

2905

5.9

76%

27655

87.7

4743.7

2919

5.8

80%

30060

100.3

5422.6

3043

5.5

90%

34920

128.3

6938.7

3279

5.0

100%

37435

144.5

7810.0

3402

4.8
The above data is measured by changing the throttle input to adjust the tension under the environment of 25°C and sea level.
