H13MD

Original Name: H13 Propulsion System for Industrial Drones

H13MD

Thrust/rotor: 45kg
Total Weight: 7890±100g/8010±100g
Recommended LiPo Battery: 24S/28S（LiPo）
Propeller: MSC 54x20 / MSC 57x20
Tube Diameter: φ60mm

H8M

Propulsion System for Industrial Drones

H8M

Thrust/rotor：2.5~3.5kg
Total Weight: 498g
Recommended LiPo Battery: 12S
Diameter X Thread Pitch: MSC 30x9.8
Powertrain Arm Tube Outer Diameter: φ30mm

H6M

Propulsion System for Industrial Drones

H6M

Thrust/rotor： 2~2.5kg
Total Weight: 454g
Recommended LiPo Battery: 12S
Diameter X Thread Pitch: MSC 22x7.8
Powertrain Arm Tube Outer Diameter: φ30mm

X6 SE

Original Name: CM-X6-SE

X6 SE

Thrust/rotor: 2~2.5kg
Weight (With Cable & Props): 373±5g
Recommended LiPo Battery: 6S (LiPo)
Propeller: 2270
Tube Diameter: 25mm

MSC 30x9.8

Original Name: ML 30*9.8"

MSC 30x9.8

Propeller Type: ML-Matt Light Carbon Fiber Unfolding Propeller
Commonly used thrust range:3.5~8kg
Ultimate thrust:20kg
Single weight:71g

MFP 22x7.0

Original Name: HF 22*7.0"

MFP 22x7.0

Propeller Type: H-Folding Carbon Plastic Propeller
Commonly used thrust range:2kg~5kg
Ultimate thrust::11kg
Single weight:66g

XRotor 3110

FPV Brushless Motor

XRotor 3110

Product Number: 30418005,30418006
KV Rating: 900KV/1150KV
Motor Weight: 89g/88g
Recommended ESC: XRotor FPV G2 65A 4in1 ESC

XRotor 3115

FPV Brushless Motor

XRotor 3115

Product Number: 30418007,30418008
KV Rating:900KV/1050KV
Motor Weight: 125g/126g
Recommended ESC: XRotor FPV G2 65A 4in1 ESC

XRotor 2807

FPV Brushless Motor

XRotor 2807

Product Number: 30418000,30418001,
30418002
KV Rating: 1300KV/1500KV/1700KV
Motor Weight: 59g/58.7g/58.4g
Recommended ESC: XRotor FPV G2 65A 4in1 ESC

XRotor 2812

FPV Brushless Motor

XRotor 2812

Product Number:30418003,30418004
KV Rating: 900KV/1100KV
Motor Weight: 83.4g/83.8g
Recommended ESC: XRotor FPV G2 65A 4in1 ESC

V5212

Battery(LiPo): 12S
KV: 275KV
Recommended Thrust/rotor: 3.5kg/Rotor
Weight（With wire): 248g
Protection level: IPX5

MSC 22x7.8

Original Name: ML 22*7.8"

MSC 22x7.8

Propeller Type: ML-Matt Light Carbon Fiber Unfolding Propeller
Commonly used thrust range:2~5kg
Ultimate thrust:12kg
Single weight:36g
