ESC Motor All-in-one Power System

MULTIROTOR

VTOL

FIXED WING

FPV

USB Link Software (USB Link V5.1.0)

HW DATA Link

RC Systems

Drone Propulsion System

Personal Travel Systems

XRotor Pro H200A 24S BLDC/ BLDC IPC

New

XRotor Pro H200A 24S BLDC/ BLDC IPC

Input Voltage: 36~108V
Continuous current :100A（Good heat dissipation）
Weight（Without Cable）: 420g
Size: 138x68x32.5mm
Communication protocol: CAN / RS485(Custom Serial port)
lsolation mode: Throttle/ communication supported

XRotor H60A(2in1) 14S FOC V1

Input Voltage: 6-14S(18-63V)
Continuous current: 15A×2 (Good heat dissipation)
Weight: 117.4g(Without wires)
Size: 77.5x47x26.8mm
Communication protocol: CAN(Custom Serial port)
Throttle signal isolated: Isolated

XRotor H60A(2in1) 14S BLDC V1

XRotor Pro H60A 6S BLDC

Input Voltage: 4-6S(12-27V)
Continuous current: 40A(Good heat dissipation)
Weight( without wire): 53g
Size: 71x32.2x16.2mm
Communication protocol: CAN(Custom Serial port)
lsolation mode: Customizable Throttle Isolation

XRotor Pro H60A 14S BLDC

Input Voltage: 6-14S(18-63V)
Continuous current: 25A(Good heat dissipation)
Weight( without wire): 67g
Size: 78.5x32.5x17.6mm
Communication protocol: CAN(Custom Serial port)
lsolation mode: Customizable Throttle Isolation

XRotor Pro H60A 6S FOC

Input Voltage: 4-6S(12-27V)
Peak Current : 40A(Good heat dissipation)
Weight( without wire): 53g
Size: 71x32.2x16.2mm
Communication protocol: CAN(Custom Serial port)
lsolation mode: Customizable Throttle Isolation

XRotor Pro H60A 14S FOC

Input Voltage: 6-14S(18-63V)
Continuous current: 25A(Good heat dissipation)
Weight( without wire): 67g
Size:78.5x32.5x17.6mm
Communication protocol: CAN(Custom Serial port)
lsolation mode: Customizable Throttle Isolation

XRotor H80A 14S FOC

Input Voltage: 6-14S（18-63V）
Continuous current:40A（Good heat dissipation）
Weight（Without Cable）: 87g
Size: 84x35x20mm
Communication protocol:CAN(Custom Serial port)
Throttle signal isolated: Customizable Throttle Isolation

XRotor H80A 14S BLDC

XRotor H100A 14S FOC V1

Input Voltage: 12~14S(44~63V)
Continuous current: 40A (Good heat dissipation)
Weight: 144.1g(Without wires)
Size: 83x59x27.4mm
Communication protocol: CAN
Throttle signal isolated: Isolated (Custom non-isolated)

XRotor H120A 14S FOC V1

Input Voltage: 12-14S(44-63V)
Continuous current: 60A (Good heat dissipation)
Weight: 185.6g(Without wires)
Size: 113x56x25.9mm
Communication protocol: CAN(Custom Serial port)
Throttle signal isolated: Isolated (Custom non-isolated)

XRotor H120A 18S FOC V1

Input Voltage: 12-18s（44-78.3V）
Continuous current: 40A (Good heat dissipation)
Weight: 234g (Without wires)
Size: 116x49.4x34.8mm
Communication protocol: CAN
Throttle signal isolated: Isolated
